The ‘all-terrain’ hedge and grass cutter!

For use up to 100 h/year, KUHN has developed the AGRI-LONGER GII Mechanical Safety Hedge and Grass Cutters with a horizontal reach of 4.30 m or 4.80 m and an available rotor circuit power of 40 hp.



Find Your Nearest Dealer Download Brochure
KUHN has developed the AGRI-LONGER GII range of Hedge and Grass Cutters designed for individual use. The AGRI-LONGER GII 4345 M and 4845 M models display an impressive design with their robust arm assembly and outstanding features. Available in 2 horizontal reaches (4.30 m and 4.80 m), the AGRI-LONGER GII with Mechanical Safety has a 40 hp rotor circuit. Our hedge and grass cutters deliver high output even on the toughest jobs. The AGRI-LONGER GII: The art of combining driving pleasure and performance!

Your Benefits

A versatile machine, for induvial use

Tackle the widest variety of jobs in complete safety!

The arm kinematics of the AGRI-LONGER GII M series is specially designed to tackle the widest variety of jobs in complete safety: ditch bottoms, narrow paths, obstacle clearance, etc. The AGRI-LONGER GII Mechanical Safety models combine user-friendly operation and versatility!

The AGRI-LONGER GII 4345 M and 4845 M Hedge and Grass Cutters feature a narrow frame that keeps the machine within the tractor width for on-road transport.
Their centered geometric design is ideal for narrow paths. Safe mowing behind the tractor wheel is therefore possible.

220° head rotation

A 220° head rotation makes it easier to work on top of hedges and in deep ditches. Visibility and safety are flawless.

User-friendly operation for individual uses

Their 4.30 or 4.80 m horizontal reach guarantees user-friendly operations for individual use, such as on farmland hedgerows, banks along a field, etc.

The clearance provided by the underarm geometry (top-side positioning of the outer boom cylinder) means the machine can overcome obstacles without the risk of snagging (fencing, road guardrails, etc.).

You will be impressed by their design!

Welded arm structure made of very high yield strength steel

The AGRI-LONGER GII Mechanical Safety Hedge and Grass Cutters are fitted with a pendulum link safety as standard. When the machine gets caught on an obstacle, the link rod at the anchor point of the lifting arm opens and prevents any risk of breakage.

The structure of the arm is a robust assembly, especially the main boom which undergoes the highest stresses. Its structure is welded using high yield strength steel (VHYS) with a 140 x 120 mm heavy-gauge box section.

For an even longer service life, all the machine’s joints, including cylinder joints, are protected against wear with greased-for-life cell-type bushings.

Rotational shaft movement is prevented to avoid premature wear or any opening up of the joints.

5 kW air-cooled radiator as standard

All the models in the AGRI-LONGER GII Mechanical Safety range are equipped as standard with a 5 kW air-cooled radiator. You will be able to enjoy the full power of your 40 hp machine. Sustained work can therefore be kept up all day long without component damage for years to come.

Quality bushcutting

The robust flail head is comprised of a reinforced casing, including:

  • a removable wear plate,
  • a 10 mm thick rotor,
  • two wire protection baffles,
  • interchangeable wear shoes,
  • a grass shroud for safety.

For quality bushcutting, the flail head is equipped with 36 Y-flails for a working width of 1.00 m. The head is fitted with a Ø133 mm adjustable sensor roller to increase the rigidity of the assembly.

For increased cutting capacity in the steepest situations, the 220° rotating flail head joint is positioned at the rear.

A full range of accessories as standard

2 types of control set-ups to choose from!

The AGRI-LONGER GII Mechanical Safety series offers two types of controls:

  • Remote cable controls for easy, reliable use. The control console is extended by a padded armrest. To increase your machine’s service life, the ‘two-way’ rotor rotation function is equipped with an anti-reversing safety device.
  • Electric joystick control for ergonomics and user-friendly operation. The joystick enables the user to electrically and simultaneously control the machine’s main functions: main boom, outer boom, flail head orientation and float position. By design, the electric control is easy to fit in the cab.

Many standard features!

Each of the machine’s components should help save time and provide user-friendly advantages with maximum safety in a whole variety of situations.

For all these reasons, we have equipped the AGRI-LONGER GII models with many standard features:

  • Fully enclosed beam housing with pivoting polymer hood,
  • Bumper with built-in lights,
  • Air-cooled radiator,
  • Floating head,
  • Two-directional rotor rotation with anti-reversing safety,
  • Control support bracket for storage,
  • Full hose protection,
  • Lift float,
  • Four adjustable stands for removal,
  • Pendulum link safety device.

Specifications

Technical characteristics

4245 M4345 M4845 M
Horizontal reach (m)4.204.304.80
Available rotor circuit power at 540 rpm (kW / hp)27/3730/4030/40
Recommended useUp to 100 hours per yearUp to 100 hours per yearUp to 100 hours per year
Recommended minimum tractor weight (tonnes)333
Minimum power required at tractor PTO (kW / hp)51/7051/7051/70
Arm safety for obstacle clearanceMechanical, pendulum link typeMechanical, pendulum link typeMechanical, pendulum link type
KinematicsCompassCompassCompass
Outer boomStraight arm (no pivot)Straight arm (no pivot)Straight arm (no pivot)
Hitch category3-Point cat 2 and 33-Point cat 2 and 33-Point cat 2 and 3
Hitch type2 stabilisers with universal joints optional2 stabilisers with universal joints optional2 stabilisers with universal joints optional
StructureMain boom with reconstituted very high yield steel structure Main boom section 144 x 120 x 6 to 15mm Outer boom tubular section 100 x 100 x 8mmMain boom with reconstituted very high yield steel structure Main boom section 144 x 120 x 6 to 15mm Outer boom tubular section 100 x 100 x 8mmMain boom with reconstituted very high yield steel structure Main boom section 144 x 120 x 6 to 15mm Outer boom tubular section 100 x 100 x 8mm
Full enclosure to protect all componentsAs standardAs standardAs standard
Bumpers with lightingAs standardAs standardAs standard
Transport height (m) with 0.5 m ground clearance3.223.223.41
Machine weight (kg)900935955
